3D-Printable Guide Bushing for the HD Tubing Notcher System
This product provides the 3D print file for the guide bushing used in the HD Tubing Notcher system.
The printed guide bushing centers the tube and establishes the correct reference location for the angle guide geometry in the steel notcher plate.
This listing is for the STL file only.
No steel parts are included.
Centers the tube within the HD Tubing Notcher
Establishes the reference point for the angle guide lines
Interfaces with the steel cap and bearing-guided file system
Ensures consistent alignment between the tube, file, and angle references
This bushing is a required component of the HD Tubing Notcher system.
Digital STL file for the HD Tubing Notcher guide bushing
Instant download after purchase
Print as many as you need for personal use
To build and use the complete HD Tubing Notcher, you must also purchase or provide:
Laser-cut steel notcher plate and cap
👉 https://marketplace.sendcutsend.com/p/C383U475/hd-tubing-notcher
(3) 3 × 6 × 2.5 mm bearings
Buy here: https://amzn.to/4r4hHyw
(6) M3 × 16 mm screws
A 3/16" diameter round file
Recommendation: https://amzn.to/4qYfuEq
Basic shop tools for cleanup and assembly
The steel components are manufactured and shipped by SendCutSend.
This product does not include any physical parts.
Designed for standard FDM printing
Material choice is up to the builder (PLA+, PETG, ABS, or similar)
The steel cap clamps over this printed bushing using M3 hardware
The steel plate must be tapped by the builder prior to final assembly
This is a digital product only — no physical items will be shipped
The steel notcher plate and cap are not included
Bearings, hardware, file, and tools are not included
Designed exclusively for the HD Tubing Notcher system
All designs © Harley Designs Inc.
